Victaulic V080761SE3 Vic-300 761 Gear-Operated Butterfly Valve – Black Coated, Grade E Seat
WWC Part No/ SKU: 816395
Brand: Victaulic
Mfg. Model: V080761SE3
Product Details
| Category | Butterfly Valve |
|---|---|
| Finish | Black Alkyd Enamel |
| Size | 8 in |
| Connection Type | Grooved End |
| Color | Black Alkyd Enamel |
| Material | Ductile Iron |
| Brand | Victaulic |
In stock
SKU
816395
$7,886.50 $2,612.35 /Each
Not Available
V080761SE3 VICTAULIC VIC-300 MASTERSEAL BUTTERFLY VALVE 8in; STANDARD NICKEL PLATED DUCTILE IRON DISC / 416 STEM; E-EPDM; GEAR V080761SE3 VPS 8 BFV VIC 300MS E GO 8vicbfv 8VBFV 8V761
Frequently Bought Together
- Designed for bi-directional, dead-end services to full working pressure
- Pressure rated up to 300 PSI/2068 KPA/21 BAR
These butterfly valves are designed for pressures ranging from vacuum to 300 psi/2065 kPa and for bi-directional, dead end services to full working pressure. Valve is provided with either 10-position handle, lever lock or gear operator.
Victaulic® Vic-300 MasterSeal™ Butterfly Valve, Series: 761, 8 in Nominal, Grooved, -30 to 250 deg F, Media: Water, Gear Actuator, 5.33 in Inlet to Outlet Length, 11.56 in Top to Inlet Center, Ductile Iron Body, Ductile Iron Disc, 416 Stainless Steel (Stem) Stem & Pin Material, Alkyd Enamel Coated, Black Oxide, 8.625 in OD x 16.63 in H
