Liberty Pumps SX34=3-141-5, 3 Phase, 2.5-4.0 Amp, 208/240/480V, Simplex Pump Control Panel
WWC Part No/ SKU: 1224543
Brand: Liberty Pumps
Mfg. Model: SX34=3-141-5
Product Details
| Category | Duplex Pump Control |
|---|---|
| Item Weight (lbs) | 19 lbs. |
| Brand | Liberty Pumps |
Not Available
SX34=3-141-5 LIBERTY 208/240/480V SIMPLEX CONTROL PANEL, 3 PH, NEMA 4X, 2.5 - 4.0 FULL LOAD AMPS, 3 FLOAT, 50 FT. CORD SX34=3-141-5 LIBERTY 208/240/480V S
- Across-the-line magnetic contactor
- Test/Auto switch
- Termil block for easy wiring
- Circuit breaker
- Green pump indicator light (interl)
- Red alarm indicator light/audible alarm
- Auxiliary contacts
- Alarm silence and test switches
This Liberty control panel was designed to provide a reliable means of controlling simplex pump systems in residential or commercial installations. It is most commonly used in sump basins, lift stations and effluent or sewage pump chambers. The NEMA 4x ultraviolet stabilized thermoplastic is made for outdoor use. This product consists of a control panel and 3-pilot-duty float switches. The floats control the OFF, ON, and ALARM functions.
